TMS320F28067PZPQ - Texas Instruments
Automotive C2000™ 32-bit MCU with 90 MHz, FPU, 256 KB flash, 100 KB RAM 100-HTQFP -40 to 125
Technical Details
| Data Bus Width | 32b |
| Frequency | 90MHz |
| Height | 0m |
| Interface | CAN, I2C, SCI, SPI, UART, USART |
| Lead Free | Lead Free |
| Length | 14mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Frequency | 90MHz |
| Max Operating Temperature | 125°C |
| Memory Size | 256kB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Number of GPIO | 54 |
| Number of I/Os | 54 |
| Number of Pins | 100 |
| Number of Programmable I/O | 54 |
| Number of Timers/Counters | 3 |
| Number of UART Channels | 2 |
| Operating Supply Voltage | 3.3V |
| Oscillator Type | Internal |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Radiation Hardening | No |
| RAM Size | 50kB |
| RoHS | Compliant |
| Thickness | 1mm |
| Watchdog Timer | Yes |
| Weight | 510.007921mg |
| Width | 14mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Texas Instruments
