TPD4E110DPWR - Texas Instruments
Quad 0.45-pF, 5.5-V, ±12-kV ESD protection diode for High Speed Interfaces 4-X2SON -40 to 125
Technical Details
| Ambient Temperature Range High | 125°C |
| Breakdown Voltage | 6.5V |
| Capacitance | 450fF |
| Clamping Voltage | 13V |
| Depth | 850µm |
| Direction | Unidirectional |
| Height | 400µm |
| Interface | LVDS, PCI, USB |
| Lead Free | Lead Free |
| Leakage Current | 20nA |
| Length | 800µm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 125°C |
| Min Breakdown Voltage | 6.5V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Channels | 4 |
| Number of Pins | 4 |
| Number of Unidirectional Channels | 4 |
| Operating Supply Voltage | 5.5V |
| Peak Pulse Current | 2.5A |
| Peak Pulse Power | 35W |
| Power Line Protection | Yes |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Standoff Voltage | 5.5V |
| RoHS | Compliant |
| Thickness | 370µm |
| Width | 800µm |
| Working Voltage | 5.5V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
