TPS3306-15DGKRG4 - Texas Instruments
Dual-processor voltage supervisor with power-fail & watchdog timer 8-VSSOP -40 to 85
Technical Details
| Case/Package | VSSOP |
| Height | 1.07mm |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | LIFEBUY |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 424mW |
| Max Supply Current | 40µA |
| Max Supply Voltage | 6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Nominal Supply Current | 40µA |
| Number of Elements | 2 |
| Number of Pins | 8 |
| Number of Voltages Monitored | 2 |
| Operating Supply Current | 15µA |
| Power Dissipation | 424mW |
| Quiescent Current | 15µA |
| Radiation Hardening | No |
| Reset | Active Low |
| Reset Timeout | 70ms |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Thickness | 970µm |
| Threshold Voltage | 2.93V |
| Undervoltage Threshold | 2.93V |
| Watchdog Timer | Yes |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| STMicroelectronics | Production | ||
| Intersil | Obsolete | ||
| MaxLinear | Obsolete | ||
| STMicroelectronics | Production | ||
| STMicroelectronics | Obsolete | ||
| Sipex | Obsolete | ||
| STMicroelectronics | Obsolete |
