TPS51117PWRG4 - Texas Instruments
1.8-V to 28-V, synchronous D-CAP buck contoller with light load efficiency 14-TSSOP -40 to 85
Technical Details
| Case/Package | TSSOP |
| Duty Cycle | 95% |
| Height | 1.2mm |
| Lead Free | Lead Free |
| Length | 5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Frequency | 550kHz |
| Max Input Voltage | 28V |
| Max Operating Temperature | 85°C |
| Max Output Current | 10A |
| Max Output Voltage | 5.5V |
| Min Input Voltage | 1.8V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 760mV |
| Number of Outputs | 1 |
| Number of Pins | 14 |
| Operating Supply Voltage | 5.5V |
| Output Current | 10A |
| Output Voltage | 5.5V |
| Packaging | Tape & Reel (TR) |
| Quiescent Current | 400µA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Thickness | 1mm |
| Topology | Buck |
| Weight | 57.209338mg |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Semtech | Obsolete | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown | ||
| Exar | Obsolete | ||
| Renesas | Obsolete | ||
| Analog Devices | Unknown | ||
| Texas Instruments | Unknown |
