TPS51120RHBRG4 - Texas Instruments
DC DC Cntrlr Dual-OUT Sync Buck 4.5V to 28V Input 32-Pin VQFN EP T/R
Technical Details
| Case/Package | VQFN |
| Duty Cycle | 88% |
| Height | 1mm |
| Lead Free | Contains Lead |
| Length | 5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Frequency | 580kHz |
| Max Input Voltage | 28V |
| Max Operating Temperature | 85°C |
| Max Output Current | 20A |
| Max Output Voltage | 5.5V |
| Min Input Voltage | 4.5V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 1.05V |
| Number of Outputs | 2 |
| Number of Pins | 32 |
| Operating Supply Voltage | 28V |
| Output Current | 20A |
| Packaging | Tape & Reel (TR) |
| Quiescent Current | 750µA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Thickness | 900µm |
| Topology | Buck |
| Weight | 71.809342mg |
| Width | 5mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Unknown | ||
| Analog Devices | EOL | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production |
