TPS61041DRVT - Texas Instruments
28-V, 250-mA Switch Boost Converter in SOT-23 for LCD and White LED Applications 6-WSON -40 to 85
Technical Details
| Case/Package | SOT-23 |
| Contact Plating | Gold |
| Dimming | PWM |
| Efficiency | 85% |
| Frequency | 1MHz |
| Height | 800µm |
| High Level Output Current | 50mA |
| Lead Free | Lead Free |
| Length | 2mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 6V |
| Max Operating Temperature | 85°C |
| Max Output Current | 50mA |
| Max Output Voltage | 28V |
| Max Supply Current | 50µA |
| Max Supply Voltage | 6V |
| Min Input Voltage | 1.8V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 1.8V |
| Number of Outputs | 1 |
| Number of Pins | 6 |
| Output Current per Channel | 215mA |
| Output Type | Adjustable |
| Output Voltage | 28V |
| Packaging | Tape & Reel (TR) |
| Power Dissipation | 500mW |
| Quiescent Current | 28µA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Switching Frequency | 1MHz |
| Thickness | 750µm |
| Topology | Boost |
| Weight | 9.695537mg |
| Width | 2mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
