TPS61050DRCR - Texas Instruments
1.2A high power white LED driver with I2C compatible interface, SON package 10-VSON -40 to 85
Technical Details
| Contact Plating | Gold |
| Frequency | 2.2MHz |
| Height | 1mm |
| Lead Free | Lead Free |
| Length | 3mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 6V |
| Max Operating Temperature | 85°C |
| Max Output Current | 1.2A |
| Max Power Dissipation | 2.4W |
| Max Supply Voltage | 6V |
| Min Input Voltage | 2.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.5V |
| Number of Outputs | 1 |
| Number of Pins | 10 |
| Number of Segments | 1 |
| Output Current | 1.2A |
| Output Voltage | 5.5V |
| Packaging | Tape & Reel (TR) |
| Power Dissipation | 2.4W |
| Quiescent Current | 8.5mA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Thickness | 900µm |
| Topology | Boost |
| Weight | 26.109911mg |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| ROHM | Production | ||
| Diodes Inc. | Obsolete | ||
| Analog Devices | Production | ||
| Texas Instruments | Production | ||
| ROHM | Obsolete |
