TPS61195RUYT - Texas Instruments
96 LED, 8-channel white LED driver for LCD backlight with SMBus interface 28-WQFN -40 to 85
Technical Details
| Case/Package | QFN |
| Contact Plating | Gold |
| Frequency | 1.2MHz |
| Height | 800µm |
| Lead Free | Lead Free |
| Length | 4mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 21V |
| Max Operating Temperature | 85°C |
| Max Output Current | 240mA |
| Max Supply Current | 3mA |
| Max Supply Voltage | 21V |
| Min Input Voltage | 4.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4.5V |
| Number of Channels | 8 |
| Number of Outputs | 8 |
| Number of Pins | 28 |
| Number of Segments | 96 |
| Output Voltage | 45V |
| Packaging | Cut Tape (CT) |
| Quiescent Current | 3mA |
| Radiation Hardening | No |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Switching Frequency | 1MHz |
| Thickness | 750µm |
| Topology | Boost |
| Width | 4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
Texas Instruments
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Texas Instruments | Unknown | ||
| Analog Devices | Production | ||
| Analog Devices | Unknown | ||
| Analog Devices | Unknown | ||
| Analog Devices | Obsolete | ||
| Analog Devices | Unknown | ||
| Analog Devices | Production | ||
| Analog Devices | Obsolete | ||
| Allegro MicroSystems | Obsolete |
