TPS61199PWP - Texas Instruments
White LED driver for LCD Monitors backlighting 20-HTSSOP -40 to 85
Technical Details
| Case/Package | HTSSOP EP |
| Frequency | 800kHz |
| Height | 0m |
| Lead Free | Lead Free |
| Length | 6.5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 30V |
| Max Operating Temperature | 85°C |
| Max Output Current | 480mA |
| Max Supply Current | 1.5mA |
| Max Supply Voltage | 30V |
| Min Input Voltage | 8V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 8V |
| Number of Channels | 8 |
| Number of Outputs | 8 |
| Number of Pins | 20 |
| Output Current | 70mA |
| Quiescent Current | 1.5mA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Thickness | 1mm |
| Topology | Boost |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Texas Instruments
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Diodes Inc. | Obsolete | ||
| Texas Instruments | Production | ||
| Semtech | EOL | ||
| Diodes Inc. | Production | ||
| Atmel | Unknown | ||
| Diodes Inc. | Production | ||
| Exar | Obsolete | ||
| MaxLinear | Obsolete | ||
| Texas Instruments | Unknown |
