TPS65150PWPG4 - Texas Instruments
Universal, compact LCD bias Power Supply with integrated VCOM Buffer 24-HTSSOP -40 to 85
Technical Details
| Case/Package | HTSSOP EP |
| Height | 1.2mm |
| Lead Free | Lead Free |
| Length | 7.8mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Frequency | 1.38MHz |
| Max Input Voltage | 6V |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 3.3W |
| Max Supply Voltage | 6V |
| Min Input Voltage | 1.8V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.8V |
| Number of Outputs | 3 |
| Number of Pins | 24 |
| Operating Supply Current | 1.9mA |
| Output Voltage | 15V |
| Power Dissipation | 3.3W |
| Quiescent Current | 1.9mA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Switching Frequency | 1.2MHz |
| Thickness | 1mm |
| Topology | Boost |
| Weight | 98.08935mg |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production | ||
| Analog Devices | Production |
