TPS715345DCKRG4 - Texas Instruments
50mA 24V ultra-low-IQ low-dropout (LDO) voltage regulator 5-SC70 -40 to 125
Technical Details
| Accuracy | 4% |
| Case/Package | SOT-5 |
| Dropout Voltage | 415mV |
| Height | 1.1mm |
| Input Bias Current | 3.2µA |
| Lead Free | Lead Free |
| Length | 2mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 24V |
| Max Operating Temperature | 125°C |
| Max Output Current | 50mA |
| Max Output Voltage | 3.45V |
| Max Power Dissipation | 320mW |
| Min Current Limit | 125mA |
| Min Input Voltage | 3V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 3.45V |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Number of Regulators | 1 |
| Output Current | 50mA |
| Output Type | Fixed |
| Output Voltage | 3.45V |
| Output Voltage Accuracy | 4% |
| Packaging | Tape and Reel |
| Polarity | Positive |
| Power Dissipation | 320mW |
| Power Rating | 320mW |
| Quiescent Current | 3µA |
| Radiation Hardening | No |
| RoHS | Compliant |
| Thickness | 900µm |
| Width | 1.25mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
