TPS73213DBVRG4 - Texas Instruments
Single Output LDO, 250mA, Fixed(1.3V), Fast Transient Response, Reverse Current Protection 5-SOT-23 -40 to 85
Technical Details
| Accuracy | 1% |
| Case/Package | SOT-23-5 |
| Input Bias Current | 400µA |
| Lead Free | Contains Lead |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 125°C |
| Max Output Current | 250mA |
| Max Output Voltage | 1.3V |
| Max Power Dissipation | 560mW |
| Min Current Limit | 250mA |
| Min Input Voltage | 1.7V |
| Min Operating Temperature | -40°C |
| Min Output Voltage | 1.3V |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Number of Regulators | 1 |
| Output Current | 250mA |
| Output Type | Fixed |
| Output Voltage | 1.3V |
| Polarity | Positive |
| Quiescent Current | 400µA |
| Radiation Hardening | No |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Unknown | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Texas Instruments | Production | ||
| Microchip | Unknown | ||
| Microchip | Production | ||
| Texas Instruments | Unknown |
