TPS92002DR - Texas Instruments
General-purpose PWM controller with 15V Turn-on Threshold for LED Lighting 8-SOIC -40 to 105
Technical Details
| Case/Package | SOIC |
| Duty Cycle | 70% |
| Fall Time | 18ns |
| Frequency | 110kHz |
| Height | 1.75mm |
| Lead Free | Lead Free |
| Length | 4.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Operating Temperature | 105°C |
| Max Supply Voltage | 21V |
| Min Operating Temperature | -40°C |
| Number of Outputs | 1 |
| Number of Pins | 8 |
| Output Current | 800mA |
| Output Voltage | 5V |
| Packaging | Digi-Reel® |
| Quiescent Current | 600µA |
| Rise Time | 35ns |
| RoHS | Compliant |
| Switching Frequency | 110kHz |
| Thickness | 1.58mm |
| Topology | Boost, Buck, Flyback |
| Width | 3.91mm |
Compliance
RoHS : Unconfirmed
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| MaxLinear | Obsolete | ||
| Diodes Inc. | Production | ||
| onsemi | EOL | ||
| Diodes Inc. | Obsolete | ||
| Infineon | Obsolete | ||
| Diodes Inc. | NRND | ||
| MaxLinear | Obsolete | ||
| MaxLinear | Obsolete | ||
| MaxLinear | Obsolete |
