UCC1806L - Texas Instruments
Low Power, Dual Output, Current Mode PWM Controller 20-LCCC -55 to 125
Technical Details
| Duty Cycle | 50% |
| Fall Time | 35ns |
| Height | 0m |
| Lead Free | Contains Lead |
| Length | 8.89mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Duty Cycle | 50% |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 14.5V |
| Min Operating Temperature | -55°C |
| Number of Pins | 20 |
| Output Current | 500A |
| Packaging | Rail/Tube |
| Radiation Hardening | No |
| Rise Time | 35ns |
| RoHS | Non-Compliant |
| Switching Frequency | 52kHz |
| Thickness | 1.83mm |
| Topology | Boost, Flyback |
| Width | 8.89mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
