UCC28221PW - Texas Instruments
IC OFFLINE SW FLYBACK 20TSSOP Converter Offline Flyback Topology 2MHz 20-TSSOP
Technical Details
| Case/Package | TSSOP |
| Duty Cycle | 77% |
| Fall Time | 10ns |
| Frequency | 2MHz |
| Height | 0m |
| Length | 6.5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Duty Cycle | 90% |
| Max Frequency | 2MHz |
| Max Operating Temperature | 105°C |
| Max Supply Voltage | 14.5V |
| Min Operating Temperature | -40°C |
| Nominal Input Voltage | 48V |
| Number of Channels | 2 |
| Number of Outputs | 2 |
| Number of Pins | 20 |
| Output Voltage | 400mV |
| Quiescent Current | 3mA |
| Radiation Hardening | No |
| Rise Time | 10ns |
| RoHS | Compliant |
| Switching Frequency | 1.1MHz |
| Thickness | 1mm |
| Topology | Flyback |
| Weight | 76.997305mg |
| Width | 4.4mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown | ||
| Texas Instruments | Unknown | ||
| Semtech | Obsolete | ||
| Semtech | Obsolete | ||
| Texas Instruments | Unknown | ||
| Analog Devices / Linear Technology | Unknown | ||
| Analog Devices / Linear Technology | Unknown | ||
| Analog Devices / Linear Technology | Unknown | ||
| Analog Devices | Production |
