195D335X9020V2T - Vishay
Surface Mount Tantalum Capacitor, 3.3 uF, 20 V, ± 10%, -55 °C, 125 °C, 1110 [2926-15 Metric]
Technical Details
| Capacitance | 3.3µF |
| Case/Package | 1410 |
| Case Code (Imperial) | 1410 |
| Case Code (Metric) | 3527 |
| China RoHS | Compliant |
| Country of Origin | Israel |
| Dissipation Factor | 6% |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Features | General Purpose |
| Height | 1.3mm |
| Height - Seated (Max) | 1.5494mm |
| Harmonized Tariff Schedule (HTS) Code | 8532.21.00.50 |
| Introduction Date | 2001-08-30 |
| Leakage Current | 700nA |
| Length | 3.63mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Tolerance | 10% |
| Voltage Rating | 20V |
| Voltage Rating (DC) | 20V |
| Width | 2.65mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
