GSOT04C-G3-08 - Vishay
Trans Voltage Suppressor Diode, 429W, 4V V(RWM), Unidirectional, 2 Element, Silicon
Technical Details
| Breakdown Voltage | 6.1V |
| Capacitance | 200pF |
| Case/Package | SOT-23-3 |
| China RoHS | Compliant |
| Clamping Voltage | 11.2V |
| Composition | Zener |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2013-03-18 |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 150°C |
| Min Breakdown Voltage | 5V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Elements | 2 |
| Number of Terminals | 3 |
| Number of Unidirectional Channels | 2 |
| Peak Pulse Current | 30A |
| Peak Pulse Power | 429W |
| Polarity | Bidirectional, Unidirectional |
| Power Line Protection | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 4V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Weight | 8.788352mg |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
