GSOT24C-E3-18 - Vishay
TO-236-3SC-59SOT-23-3 2 Surface Mount 2 Zener Tvs Diode 30V 5A 8/20mus 235W 65pF
Technical Details
| Breakdown Voltage | 30V |
| Capacitance | 65pF |
| Case/Package | SOT-23 |
| China RoHS | Compliant |
| Clamping Voltage | 41V |
| Composition | Zener |
| Depth | 1.43mm |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2013-03-18 |
| Leakage Current | 1µA |
| Length | 3.1mm |
| Lifecycle Status | Obsolete |
| Max Operating Temperature | 150°C |
| Min Breakdown Voltage | 27V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Elements | 2 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Number of Unidirectional Channels | 2 |
| Peak Pulse Current | 5A |
| Peak Pulse Power | 235W |
| Polarity | Bidirectional, Unidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 24V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Weight | 8.788352mg |
| Working Voltage | 24V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Avnet |
US: 0
|
$ | 0.0637 | |||||||
| Mouser |
US: 5169
|
$ | 0.43 | 0.291 | 0.291 | 0.168 | 0.112 | 0.08 | ||
| Newark |
US: 0
|
$ | 0.113 | |||||||
Non-Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Fly-Wing Technology |
HK: 1783
|
$ | 0.3415 | 0.3222 | 0.3222 | 0.3039 | 0.2705 | 0.2705 | ||
| XingHuan International |
CN: 60000
|
$ | ||||||||
