SMF7V5A-HM3-08 - Vishay
Esd Protection Diode Smf Do219Ab7.5V, ir0.1 A, ip15.5A, p1Kw, cd773Pf, 30Kv |Vishay SMF7V5A-HM3-08
Technical Details
| Breakdown Voltage | 8.82V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 12.9V |
| Composition | Zener |
| Depth | 1.9mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Forward Voltage | 2.5V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2013-11-19 |
| Leakage Current | 100nA |
| Length | 2.9mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 9.3V |
| Max Operating Temperature | 150°C |
| Min Breakdown Voltage | 8.33V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Packaging | Tape & Reel (TR) |
| Peak Pulse Current | 15.5A |
| Peak Pulse Power | 1kW |
| Peak Reverse Current | 100nA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 7.5V |
| RoHS | Compliant |
| Working Voltage | 7.5V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
