Technical Details
| Ambient Temperature Range High | 100°C |
| Case/Package | Radial |
| Color | Green |
| Depth | 3.2mm |
| Dominant Wavelength | 575nm |
| Forward Current | 7mA |
| Forward Voltage | 2.4V |
| Height | 4.5mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Length | 3.2mm |
| Lens Style | Circular, Colored, Diffused |
| Lifecycle Status | Production |
| Luminous Intensity | 1.2mcd |
| Max Junction Temperature (Tj) | 100°C |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Packaging | Tape & Reel |
| Peak Wavelength | 565nm |
| Power Dissipation | 20mW |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Voltage | 6V |
| RoHS | Compliant |
| Shape | Round |
| Terminal Pitch | 2.54mm |
| Test Current | 2mA |
| Viewing Angle | 50° |
| Wavelength | 575nm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
