VCUT0714A-HD1-GS08 - Vishay
VCUT Series 30 V Bi-Directional Asymmetrical Single Line ESD-Protection -SOD-882
Technical Details
| Breakdown Voltage | 14.5V |
| Capacitance | 8pF |
| China RoHS | Compliant |
| Clamping Voltage | 30V |
| Composition | Zener |
| Country of Origin | Germany |
| Current Rating | 100nA |
| Depth | 650µm |
| Direction | Bidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Height | 450µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2008-04-17 |
| Lead Free | Lead Free |
| Leakage Current | 100nA |
| Length | 1.05mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 14.5V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 63W |
| Max Reverse Leakage Current | 100nA |
| Min Breakdown Voltage | 7.3V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Bidirectional Channels | 1 |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 14V |
| Peak Pulse Current | 5A |
| Peak Pulse Power | 63W |
| Peak Reverse Current | 100nA |
| Polarity | Bidirectional |
| Power Line Protection | No |
| Radiation Hardening | No |
| Reverse Breakdown Voltage | 14.5V |
| Reverse Standoff Voltage | 7V |
| RoHS | Compliant |
| Schedule B | 8536300000, 8536300000|8536300000|8536300000|8536300000|8536300000 |
| Termination | SMD/SMT |
| Test Current | 1mA |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Littelfuse | Obsolete | ||
| onsemi | Obsolete | ||
| Littelfuse | Production | ||
| Littelfuse | Production | ||
| Littelfuse | Production | ||
| Infineon | Obsolete | ||
| Diodes Inc. | Production | ||
| Semtech | Production | ||
| Bourns | Obsolete | ||
| STMicroelectronics | Obsolete |
