Technical Details
| Actuator Length | 500µm |
| Actuator Material | Liquid Crystal Polymer, Polymer |
| Color | White |
| Contact Current Rating | 50mA |
| Contact Material | Stainless Steel, Steel |
| Contact Plating | Silver |
| Contact Resistance | 100mΩ |
| Current Rating | 50mA |
| Height | 2.5mm |
| Illumination Type | Illuminated, Non-Illuminated |
| Insulation Resistance | 100MΩ |
| Lead Free | Lead Free |
| Length | 6.2mm |
| Max Operating Temperature | 85°C |
| Mechanical Life | 500kcycles |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Operating Force | 2.55N |
| Packaging | Tape and Reel |
| REACH SVHC | No |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 250µm |
| Termination | SMD/SMT |
| Throw Configuration | SPST |
| Voltage Rating | 12V |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Multicomp | Production | ||
| Multicomp | Production | ||
| Wurth Elektronik | Unknown | ||
| Wurth Elektronik | Unknown | ||
| Wurth Elektronik | Unknown | ||
| Wurth Elektronik | Unknown | ||
| Wurth Elektronik | Unknown | ||
| E-Switch | Production | ||
| E-Switch | Production | ||
| C&K Components | Unknown |
Authorized Distributors
Non-Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Fly-Wing Technology |
HK: 2757
|
$ | 0.4287 | 0.4045 | 0.4045 | 0.3816 | 0.3396 | 0.3396 | ||
| Bettlink |
HK: 2719
|
$ | 0.4794 | 0.3551 | 0.3551 | 0.3088 | 0.2886 | 0.2593 | ||
