431256083716 - Wurth Elektronik
Tactile Switch, 0.05A, 12Vdc, 160Gf, Tht Rohs Compliant: Yes |Wurth Elektronik 431256083716
Technical Details
| Actuator Material | Liquid Crystal Polymer, Polymer |
| Contact Plating | Silver |
| Current Rating | 50mA |
| Diameter | 3mm |
| Height | 8.35mm |
| Illumination Type | Non-Illuminated |
| Insulation Resistance | 100MΩ |
| Max Operating Temperature | 85°C |
| Mechanical Life | 200kcycles |
| Min Operating Temperature | -40°C |
| Packaging | Bulk |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 250µm |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating | 12V |
Compliance
RoHS : Unconfirmed
Images
RS
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Wurth Elektronik | Unknown | ||
| Wurth Elektronik | Unknown | ||
| E-Switch | Obsolete | ||
| C&K Components | Obsolete | ||
| C&K Components | Obsolete | ||
| Wurth Elektronik | Unknown | ||
| C&K Components | Obsolete | ||
| E-Switch | Production | ||
| C&K Components | Obsolete | ||
| C&K Components | Obsolete |
