Technical Details
| Actuator Length | 500µm |
| Actuator Material | Liquid Crystal Polymer, Polymer |
| Color | White |
| Contact Current Rating | 50mA |
| Contact Material | Stainless Steel, Steel |
| Contact Plating | Silver |
| Current Rating | 50mA |
| Dominant Wavelength | 460nm |
| Forward Current | 150mA |
| Forward Voltage | 3.3V |
| Height | 2.5mm |
| Illumination Type | Illuminated, LED |
| Insulation Resistance | 100MΩ |
| Length | 6.8mm |
| Luminous Intensity | 80mcd |
| Max Operating Temperature | 85°C |
| Mechanical Life | 50kcycles |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Peak Reverse Current | 50µA |
| Peak Wavelength | 465nm |
| REACH SVHC | No |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 250µm |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| Viewing Angle | 150° |
| Voltage Rating | 12V |
| Width | 4.5mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
