465RG11172501 - Wurth Elektronik
Switch Push Button N.O. SPST Button 0.1A 12VDC Momentary Contact Thru-Hole PC Pins Tray
Technical Details
| Current Rating | 100mA |
| Dominant Wavelength | 525nm |
| Forward Current | 100mA |
| Forward Voltage | 2.1V |
| Height | 19.5mm |
| Insulation Resistance | 100MΩ |
| Luminous Intensity | 350mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Peak Reverse Current | 10µA |
| Peak Wavelength | 530nm |
| Power Dissipation | 120mW |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Viewing Angle | 120° |
| Voltage Rating | 12V |
Compliance
RoHS : Unconfirmed
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| C&K Components | Production | ||
| C&K Components | Production | ||
| C&K Components | Obsolete | ||
| APEM | Production | ||
| C&K Components | Production | ||
| APEM | Production | ||
| C&K Components | Production | ||
| C&K Components | Production | ||
| C&K Components | Production | ||
| C&K Components | Production |
