YC124-JR-070RL - Yageo Group
Res Thick Film Array 0 Ohm ISOL Molded 8-Pin 0804(4 X 0402) Convex SMD Paper T/R
Technical Details
| Case/Package | 0804 |
| Case Code (Imperial) | 0402 |
| China RoHS | Non-Compliant |
| Circuit Type | Isolated |
| Composition | Thick Film |
| Depth | 1mm |
| Height | 450µm |
| Lead Free | Lead Free |
| Length | 2mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 155°C |
| Military Standard | Not |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Circuits | 4 |
| Number of Contacts | 8 |
| Number of Elements | 1 |
| Number of Pins | 8 |
| Number of Resistors | 4 |
| Number of Terminals | 8 |
| Packaging | Cut Tape |
| Power Dissipation | 62.5mW |
| Power Per Element | 62.5mW |
| Power Rating | 63mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Resistance | 0Ω |
| RoHS | Compliant |
| Temperature Coefficient | 200ppm/°C |
| Terminal Pitch | 500µm |
| Termination | Convex |
| Tolerance | 5% |
| Voltage Rating | 25V |
| Voltage Rating (AC) | 50V |
| Voltage Rating (DC) | 25V |
| Width | 1mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
TME
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| ROHM | Production | ||
| Yageo Group | Production | ||
| ROHM | Obsolete | ||
| ROHM | Obsolete | ||
| Yageo Group | Obsolete | ||
| Yageo Group | Production | ||
| Yageo Group | Production | ||
| Bourns | Production | ||
| CTS Components | Production | ||
| CTS Components | Production |
