EZ80F92AZ020EG - Zilog
eZ80F92 Series 256 kB Flash 8 kB RAM 20 MHz 8-Bit Microcontroller - LQFP-100
Technical Details
| Access Time | 20µs |
| Case/Package | LFQFP |
| China RoHS | Compliant |
| Core Architecture | Z8 |
| Data Bus Width | 8b |
| Frequency | 20MHz |
| Height - Seated (Max) | 1.6mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.31.00.15 |
| Interface | I2C, IrDA, SPI, UART, USART |
| Introduction Date | 2003-02-17 |
| Lead Free | Lead Free |
| Length | 14mm |
| Max Frequency | 20MHz |
| Max Operating Temperature | 105°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 128kB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Number of I/Os | 24 |
| Number of Pins | 100 |
| Number of Programmable I/O | 24 |
| Number of Terminals | 100 |
| Number of Timers/Counters | 6 |
| Operating Supply Voltage | 3.3V |
| Oscillator Type | Internal |
| Peripherals | Brown-out Detect/Reset, I2C, POR, WDT |
| Radiation Hardening | No |
| RAM Size | 8kB |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 500µm |
| Watchdog Timer | Yes |
| Width | 14mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
