Technical Details
| Case/Package | DIP |
| China RoHS | Compliant |
| Core Architecture | Z8 |
| Data Bus Width | 8b |
| Frequency | 20MHz |
| Height - Seated (Max) | 4.49mm |
| Lead Free | Lead Free |
| Length | 26.16mm |
| Max Frequency | 20MHz |
| Max Operating Temperature | 70°C |
| Max Power Dissipation | 430mW |
| Max Supply Voltage | 3.6V |
| Memory Size | 8kB |
| Memory Type | FLASH |
| Min Operating Temperature | 0°C |
| Min Supply Voltage | 2.7V |
| Number of I/Os | 17 |
| Number of Pins | 20 |
| Number of Programmable I/O | 23 |
| Number of Terminals | 20 |
| Number of Timers/Counters | 2 |
| Operating Supply Voltage | 3V |
| Oscillator Type | Internal |
| Peripherals | Brown-out Detect/Reset, POR, PWM, WDT |
| Radiation Hardening | No |
| RAM Size | 256B |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Temperature Grade | Commercial |
| Terminal Pitch | 2.54mm |
| Watchdog Timer | Yes |
| Width | 7.62mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
