Results 1 - 10 of 38659

⇆ Metric

Product Details					Compliance							Dimensions					Physical						Supply Chain						Technical
Image		Part Summary	Avg Price	Lifecycle Status	Ratings	Radiation Hardening	RoHS	REACH SVHC	Approvals	Lead Free	China RoHS	Diameter	Height	Length	Width	Depth	Case/Package	Mount	Number of Pins	Weight	Contact Material	Number of Terminals	Lifecycle Status	Export Control Classification Number (ECCN) Code	Introduction Date	Harmonized Tariff Schedule (HTS) Code	Country of Origin	Max Operating Temperature	Min Operating Temperature	Throw Configuration	Contact Current Rating	Max Current Rating	Termination	Coil Voltage (DC)	Release Time	Coil Power	Max Voltage Rating (DC)	Contact Voltage Rating (AC)	Coil Type	Operate Time	Relay Type	Coil Current	Response Time	Packaging	Coil Resistance	Max Voltage Rating (AC)	Electrical Life	Sealable	Current Rating	Contact Resistance	Insulation Resistance	Power Consumption	Voltage Rating (AC)	Schedule B	Number of Contacts	Switching Current	Ambient Temperature Range High	Dropout Voltage	Number of Poles	Type
					+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter	+filter
		Panasonic SFS2-DC12V	USD 12.375 All Prices	Production			Compliant	Yes					24 mm	40 mm	13 mm	13 mm		Through Hole	10	20 g	Gold, Silver, Tin		Production	EAR99	2006-02-27	8536.41.00.20		85 °C	-40 °C	4PST	6 A	6 A	PC Pin	9 V	20 ms	360 mW	30 V	250 V	Non-Latching	20 ms	Safety	30 mA	20 ms	Box	400 Ω	250 V	100 kcycles		6 A				250 V		4	6 A			4
		Omron G6C-2117P-US-DC12	USD 6.0408 All Prices	Production			Compliant			Lead Free			10 mm	20 mm				Through Hole	6	5.6 g	Cadmium, Silver	4	Production					70 °C	-25 °C	DPST	8 A	8 A	PC Pin	8.4 V	10 ms	200 mW	125 V	380 V	Non-Latching	10 ms	General Purpose	17 mA	10 ms		720 Ω	380 V	100 kcycles		8 A	30 mΩ	1 GΩ	200 mW		8536490050	1	8 A	70 °C
		Panasonic APAN3124	USD 2.76 All Prices	Production			Compliant	Yes		Lead Free			12.5 mm	20 mm				Through Hole			Gold, Silver		Production	EAR99	2016-04-27	8536.49.00.50		90 °C	-40 °C	SPST	5 A	5 A	PC Pin	16.8 V	5 ms	110 mW	110 V	250 V	Non-Latching	10 ms	General Purpose	5 mA	10 ms		5.236 kΩ		50 kcycles	MOISTURE PROOF, RT3	5 A	30 mΩ					1	5 A	90 °C
		Panasonic AHES4191	USD 12.19 All Prices	Production			Compliant	Yes					40 mm	36 mm				Through Hole			Silver, Tin		Production	EAR99	2015-05-14	8536.41.00.20		55 °C	-40 °C	3PST	1 A	1 A	PC Pin	9 V	10 ms	1.88 W	30 V	277 V	Non-Latching	30 ms	General Purpose	157 mA	30 ms	Box	76.6 Ω		100 kcycles	MOISTURE PROOF	40 A	100 Ω					3	40 A	70 °C
		Panasonic APAN314H	USD 3.511 All Prices	Production			Compliant	Unknown		Lead Free			12.8 mm					Through Hole			Gold, Silver		Production	EAR99	2024-09-12			90 °C	-40 °C	SPST	5 A		PC Pin	4.5 V	5 ms	110 mW			Non-Latching	10 ms	General Purpose	24.4 mA			184 Ω				5 A	30 mΩ					1	5 A	90 °C
		Panasonic ADJH23024	USD 8.20 All Prices	Production			Compliant						30.5 mm										Production													2 W						83.3 mA			288 Ω				50 A	100 Ω					1	50 A	85 °C
		Panasonic AHES3292	USD 14.7705 All Prices	Production			Compliant	Yes					40.3 mm					Through Hole			Silver, Tin		Production					55 °C	-40 °C	DPST	35 A		PC Pin	24 V	10 ms	1.88 W			Non-Latching	30 ms	General Purpose	78 mA			306.4 Ω				40 A	100 Ω					2	40 A	70 °C
		TE Connectivity 4-1904124-3	USD 2.5275 All Prices	Production			Compliant	Yes			Compliant		25.4 mm	23 mm	15.494 mm			Plug-In		16 g	Silver		Production	EAR99	2020-08-19	8536.41.00.50		125 °C	-40 °C	SPDT	30 A	30 A	Plug	12 V		1.2 W	12 V		Non-Latching		Relay				119 Ω				30 A								125 °C
		Panasonic HE1AN-W-DC9V-Y6	USD 22.51 All Prices	Production			Compliant	Yes		Lead Free			39.1 mm	38 mm				PCB, Through Hole	4		Silver		Production					55 °C	-50 °C	SPST	90 A	90 A	PC Pin	9 V	10 ms	1.92 W			Non-Latching	30 ms	General Purpose	213 mA			42.2 Ω	277 V			90 A	10 Ω				8536490075, 8536490075\|8536490075\|8536490075\|8536490075\|8536490075	1	90 A	85 °C	900 mV
		Omron LY2F-DC12	USD 8.3333 All Prices	Production		No	Compliant	Unknown	CSA, UL, VDE	Lead Free			35.56 mm	43.94 mm	22.6 mm	22.5 mm		Chassis Mount, Flanges, Socket, Surface Mount	8		Silver		Production	EAR99	2005-03-16	8536.41.00.20	Indonesia	55 °C	-25 °C	DPDT	10 A	10 A	Quick Connect	9.6 V	25 ms	900 mW	24 V	110 V	Non-Latching	25 ms	General Purpose	75 mA	25 ms	Bulk	160 Ω	250 V	500 kcycles		10 A			900 mW	250 V		1		55 °C			Electromechanical

Results 1 - 10 of 38659
