TS5205CX525 - Taiwan Semiconductor
150MA 2.5V Ultra Low Dropout Voltage Regulator With Enable
Technical Details
| Breakdown Voltage | 51V |
| Case/Package | SOT-25 |
| China RoHS | Compliant |
| Clamping Voltage | 70.1V |
| Collector Base Voltage (VCBO) | -40V |
| Collector Emitter Saturation Voltage | -400mV |
| Collector Emitter Voltage (VCEO) | 50V |
| Continuous Collector Current | -200mA |
| Country of Origin | Taiwan |
| Drain to Source Voltage (Vdss) | -60V |
| Dropout Voltage | 170mV |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Emitter Base Voltage (VEBO) | 40V |
| Forward Voltage | 1V |
| Gain Bandwidth Product | 1MHz |
| Gate to Source Voltage (Vgs) | -1.5V |
| hFE Min | 100 |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Input Capacitance | 436pF |
| Introduction Date | 2005-10-05 |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Forward Surge Current (Ifsm) | 2.5A |
| Max Junction Temperature (Tj) | 150°C |
| Max Repetitive Reverse Voltage (Vrrm) | 250V |
| Max Reverse Leakage Current | 1µA |
| Max Supply Voltage | 20V |
| Min Supply Voltage | 3V |
| Nominal Supply Current | 25nA |
| Number of Channels | 2 |
| Number of Outputs | 1 |
| Number of Terminals | 5 |
| Output Current | 150mA |
| Output Voltage | 2.5V |
| Peak Pulse Current | 21.4A |
| Peak Pulse Power | 1.5kW |
| Power Dissipation | 150mW |
| Quiescent Current | 1.3mA |
| REACH SVHC | Yes |
| Reference Voltage | 1.25V |
| Response Time | 1.3µs |
| Reverse Recovery Time | 50ns |
| Reverse Standoff Voltage | 24V |
| RoHS | Compliant |
| Terminal Pitch | 950µm |
| Test Current | 2.5mA |
| Voltage Tolerance | 1% |
| Zener Voltage | 75V |
