V62/06652-07XE - Texas Instruments
Enhanced Product Cap-Free Nmos 150-Ma Low Dropout Regulator With Reverse Current Protection
Technical Details
| Accuracy | 1% |
| Case/Package | SOT-23 |
| Height | 1.45mm |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 5.5V |
| Max Operating Temperature | 125°C |
| Max Output Current | 150mA |
| Max Output Voltage | 3.3V |
| Max Power Dissipation | 638mW |
| Min Input Voltage | 1.7V |
| Min Operating Temperature | -55°C |
| Min Output Voltage | 3.3V |
| Number of Outputs | 1 |
| Number of Pins | 5 |
| Output Current | 150mA |
| Output Type | Fixed |
| Output Voltage | 3.3V |
| Polarity | Positive |
| Quiescent Current | 400µA |
| Radiation Hardening | No |
| Reference Voltage | 1.21V |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Thickness | 1.2mm |
| Width | 1.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Texas Instruments | Production | ||
| Diodes Inc. | Obsolete | ||
| ROHM | Production | ||
| Seiko | Unknown | ||
| Micrel | Unknown | ||
| Taiwan Semiconductor | Production | ||
| Seiko | Unknown | ||
| onsemi | Obsolete | ||
| Fairchild Semiconductor | Obsolete | ||
| Torex | Production |
